7/8" ROAD Handlebars - Features
The following features are integral to the Renthal 7/8" handlebars.
- 7/8" (22mm) external diameter to fit most standard sized clamps and controls
- 7010 T6 Aluminium, which Renthal has exclusive rights to this specially developed alloy, for the manufacture of handlebars.
- High impact strength, lightweight and excellent vibration dampening
- Shot peened surface finish to help prevent fatigue failure
- Knurling - Grip end only - increases bonding between bar and grip
- No knurling in clamp area, this could cause a stress riser and lead to fatigue failure
- Anodising - a 15 step anodising process forms an integral coating giving protection against corrosion
- Renthal's copyrighted, bonded lightweight single bolt clamping system for the cross-brace* , greatly increases strength whilst still allowing flex
- Laser etched positioning grid
- The highest quality - 35 individual steps/processes required in the production
of each bar and 58 separate quality checks made. - A specially developed injection moulded crossbar pad is included with every handlebar.
- Please note that Renthal road handlebars do not come fitted with a cross-brace. The cross-brace is fitted to all Renthal 7/8" MX handlebars and the street fighter handlebars.
PLEASE NOTE THAT ALL DIMENSIONS ARE GIVEN IN mm.
7/8" APPLICATIONS - ROAD: | Part No | Dim A | Dim B | Dim C | Dim D | Dim E |
ROAD HIGH | 756-01 | 710 | 120 | 105 | 185 | 105 |
ROAD LOW | 754-01 | 730 | 105 | 75 | 185 | 125 |
ROAD MEDIUM | 755-01 | 725 | 115 | 85 | 185 | 105 |
ROAD ULTRA LOW | 758-01 | 725 | 75 | 50 | 185 | 95 |
